AFT-5000HK-R
MASS FLOW TYPE
Do not require complicate formula to find out the leakage.
The high precise MASS FLOW SENSOR indicates signal directly, so it is easy to check leakage and accurate.
The fluorescent indicator was used on the display for easier viewing over long distance.
CPU processing speed has been improved by applying 32 bit.
The high precise MASS FLOW SENSOR indicates signal directly, so it is easy to check leakage and accurate.
The fluorescent indicator was used on the display for easier viewing over long distance.
CPU processing speed has been improved by applying 32 bit.
Key Feature
1. Data can be stored in USB memory.(Available data analysis to print out in Excel)
2. PARAMETER settings can be preserved on a USB memory.
3. RS-232C serial communication is possible.
4. Pressure and amount of leakage can be displayed on the LEAK.
5. Bluetooth commynication is available.(option)
(A separate action for sires does not requi8re since its's wireless.)
6. Automatic regulator can be attatched.(option)
(Test pressure can respond to different multiple WORK.)
2. PARAMETER settings can be preserved on a USB memory.
3. RS-232C serial communication is possible.
4. Pressure and amount of leakage can be displayed on the LEAK.
5. Bluetooth commynication is available.(option)
(A separate action for sires does not requi8re since its's wireless.)
6. Automatic regulator can be attatched.(option)
(Test pressure can respond to different multiple WORK.)
Specification
| ITEM | AFT 5100HK-R | AFT 5300HK-R | AFT 5600HK-R |
|---|---|---|---|
| Pressure display | kPa, bar, Psi | ||
| Leak display | Pa, ccm | Pa, ccm | ccm,ccs |
| Method | Difference Sensor | Pressure Decay | Mass Flow |
| Function | Work management system, electric regulator, printer out, RS-232C/Bluetooth communication(Option) | ||
| Test Pressure |
L-TYPE 1kPa ~ 50kPa / M-TYPE 5kPa ~ 200kPa H-TYPE 5kPa ~ 800kPa / V-TYPE -5kPa ~ -101kPa |
||
| Minimum display | 1 Pa | 10 Pa | 0.01 ccm or 0.1 ccm |
| Temperature | 5 ~ 50℃ | ||
| Time setting | Pressure, Balance, Detection (0 ~ 999.9sec) | ||
| CH Number | 32 Channel(32 Works) | ||
| Output signal | -NG, +NG, OK, GROSS LEAK("a" contact) below 0.3A | ||
| Power | AC100 ~ 240AVC, 150VA | ||
| Weight | about 11kg | ||
